| Model |
NP7560M ( V360WNMQ ) |
| Processor |
Intel Core Ultra 9 Processor 290HX Plus (2.7 GHz, up to 5.5 GHz Turbo Frequency), 8 P-cores & 16 E-cores / 24 Threads, 36MB Intel Smart Cache, TDP: 55W
Support CPU over clocking depends on CPU SKU (Both of base frequency and ratio) |
| Chipset |
Intel HM870 Express Chipset |
| Memory |
Supports Dual Channel DDR5
Two 262Pin SODIMM sockets, support for DDR5 5600MHz (Real operation frequency depends on memory module and configuration)
Expandable up to 96GB, depends on 8GB/16GB/32GB/48GB SODIMM module. |
| Display |
16” QHD+ (2560×1600) 300Hz, Wide View Angle, Matte Finished |
Graphics
Processor |
Switchable GPU by Microsoft Hybrid Graphics – NVIDIA GeForce RTX 5050 GPU / Intel Graphics
Support 4 active displays
NVIDIA GeForce RTX 5050 Laptop GPU
– 8GB GDDR7 Video RAM
– Microsoft DirectX 12
– Support PCIe Gen5
– Support Dynamic Boost
– Maximum TGP: 115 W (including 15W Dynamic Boost 2.0)
Intel Graphics (Integrated in Core Ultra 9 Processor)
– Ray Tracing
– Variable Rate Shading
– Microsoft DirectX 12 compatible
– Intel DLBoost: DP4A
|
| Storage |
Three M.2 2280 SSD PCIe Gen 4×4 interface (RAID 0/1/5) |
| Audio System |
High Definition audio interface
Built-in Array Microphone
2 Built-in Speakers
Sound Blaster Studio+ |
| Pointing Device |
Built in Click pad with Microsoft PTP multi-gesture and scrolling function |
| Keyboard |
Multi languages, Single Zone Multi-Color illuminated full size keyboard with numeric pad. (15 colors to select) |
| I/O Ports |
1 HDMI output Port (with HDCP)
1 DisplayPort 2.1 over USB 3.2 Gen 2 Port (Type C)
1 DisplayPort 2.1 over USB 3.2 Gen 2 port (Type C) with Power Delivery DC-in
1 USB 3.2 Gen 2 Port (Type A)
1 USB 3.2 Gen 1 Port (Type A)
1 2-in-1 Audio Jack (Headphone / Microphone)
1 RJ-45 LAN (10/100/1000Mbps)
1 DC-in Jack |
| Slots |
Four M.2 Card Slots
– 1st for WLAN Combo M.2 2230 Card with PCIe and USB interface
– 2nd for SSD M.2 2280 Card with PCIe Gen 4×4 interface
– 3rd for SSD M.2 2280 Card with PCIe Gen 4×4 interface
– 4th for SSD M.2 2280 Card with PCIe Gen 4×4 interface |
| Communication |
Built-in Gigabit Ethernet LAN
Intel Wireless Wi-Fi 7 BE200 + Bluetooth, M.2 interface |
| Security |
Security (Kensington Type) Lock Slot
Intel PTT (Platform Trust Technology) |
| Power System |
Embedded 4 cells Polymer battery pack 73WH
Full Range AC-in 100~240V, 50~60Hz, 230W AC Adapter, DC output 20V, 11.5A |
| OS Support |
Windows 11 (64-bit) |
| Certificate |
Windows 11 (64-bit) Logo
HDMI Logo |
| Physical Characteristic |
5.52 LBs including bare bone and Battery Pack
14.21″ (w) x 10.20″ (d) x 1″ ~ 1.22″ (h) |
| Other Features |
Built-in 2.0M FHD Video Camera with TNR
FlexiCharger
Intel DTT (Dynamic Tuning Technology) |
|
Specifications are subject to change without notice |
