| Model |
NP9561R ( X560WNR1-G ) |
| Processor |
Intel Core Ultra 9 Processor 290HX Plus (2.7 GHz, up to 5.5 GHz Turbo Frequency), 8 P-cores & 16 E-cores / 24 Threads, 36MB Intel Smart Cache, TDP: 55W
Support CPU over clocking depends on CPU SKU (Both of base frequency and ratio) |
| Chipset |
Intel HM870 Express Chipset |
| Memory |
Supports Dual Channel DDR5
Two 262Pin SODIMM sockets, support for DDR5 5600MHz (Real operation frequency depends on processor and memory module)
Expandable up to 96GB, depends on 8GB/16GB/32GB/48GB SODIMM module |
| Display |
16” QHD+ (2560×1600) 300Hz, Wide View Angle, 72% NTSC, G-Sync Display, Matte Finished |
Graphics
Processor |
NVIDIA Advanced Optimus (Dynamic Display Switching) Technology
Support 4 active displays via HDMI x1 and Thunderbolt 4 x2
NVIDIA GeForce RTX 5070 Ti Laptop GPU
– 12GB GDDR7 Video RAM
– Microsoft DirectX 12
– Support PCIe Gen5
– Maximum TGP: 140 W (including 25W Dynamic Boost)
Intel Graphics (Integrated in Core Ultra 9 Processor)
– Ray Tracing
– Variable Rate Shading
– Microsoft DirectX 12 compatible
– Intel DLBoost: DP4A
|
| Storage |
Three M.2 2280 SSD PCIe Gen4x4 interface, with support one compatible with PCIe Gen5x4 interface |
| Audio System |
High Definition audio interface
Built-in Array Microphone
Built-in two 2W speakers
Sound Blaster Studio Pro 2 |
| Pointing Device |
Built-in Click pad with Microsoft PTP multi-gesture and scrolling function |
| Keyboard |
Multi-languages, 4-Zone full Color illuminated full size isolated keyboard with numeric pad |
| I/O Ports |
1 HDMI output Port (with HDCP)
2 Thunderbolt 4 Combo Ports with Power Delivery DC in (Type C)
2 USB 3.2 Gen2 Ports (Type A, with 1 x powered USB port, AC/DC)
1 2-in-1 Audio Jack (Headphone / Microphone)
1 RJ-45 LAN (10/100/1000/2500Mbps) |
| Card Reader |
Micro SD Push-Push Card reader |
| Slots |
Four M.2 Card Slots
– 1st for WLAN Combo M.2 2230 Card with PCIe and USB interface
– 2nd for SSD M.2 2280 Card with PCIe Gen 4×4 / Gen 5×4 interface
– 3rd for SSD M.2 2280 Card with PCIe Gen 4×4 interface
– 4th for SSD M.2 2280 Card with PCIe Gen 4×4 interface |
| Communication |
Built-in Killer 2.5 Gigabit Ethernet LAN
Intel Wireless Wi-Fi 7 BE200 + Bluetooth, M.2 interface |
| Security |
Security (Kensington Type) Lock Slot
Intel PTT (Platform Trust Technology) |
| Power System |
Embedded 4 cells Polymer battery pack 80WH
Full-Range AC-in 100~240V, 50~60Hz, 280W AC Adapter, DC output 20V, 14A |
| OS Support |
Windows 11 (64-bit) |
| Certificates |
Windows 11 (64-bit) Logo
HDMI Logo |
| Weight and Dimensions |
4.96 lbs. including battery pack
14.01″ (w) x 10.67″ (d) x 0.78″ (h) |
| Other Features |
Metal top and bottom case
Rear Light Bar Design
Built-in 5.0M Hello Camera with TNR (Temporal Noise Reduction), SecureBIO and Human Presence Detection
Camera Privacy Shutter
Vapor Chamber Thermal Design
FlexiCharger
Intel Dynamic Tuning Technology
NVIDIA G-Sync Technology at Dynamic Display Switch mode |
|
Specifications are subject to change without notice |
